Horizontal wind mill

Get a Price/Quote

MOQ : 1 Unit

Horizontal wind mill Specification

Features
Low noise operation, Robust structure, High wind energy conversion efficiency, Weather resistant

Efficiency
Over 35%

Input Voltage
48 V

Maintenance Type
Low Maintenance

Product Type
Horizontal Wind Mill

Material
High-grade steel, Aluminum Alloy

Number of Cells
3 Blades

Power
3 KW

Operating Temperature
-20C to 60C

Max Voltage
60 V

Max System Voltage
100 V

Output Voltage
48 V DC

Cable Length
10 meters

Switch Mode
Automatic

Size
Large

Dimension (L*W*H)
2600 x 1200 x 3400 mm

Color
White and Blue

Weight
245 kg

Application
Residential, Commercial, Agriculture

Type Of Technology
Aerodynamic Horizontal Axis Wind Turbine

Installation Type
Ground Mounted

Brake System
Electromagnetic & Manual Brake

Generator Type
Permanent Magnet Synchronous Generator

Annual Energy Output
5000 kWh (approx., at rated wind speed)

Noise Level
<40 dB

Protection
Over-speed, Over-voltage, Lightning protection

Tower Height
10 meters

Controller Type
MPPT Charge Controller

Cut-in Wind Speed
3 m/s

Survival Wind Speed
50 m/s

Packaging Type
Export Standard Wooden Box

Rated Wind Speed
12 m/s

Rotor Diameter
2.6 meters

Blade Material
Reinforced Fiberglass

Horizontal wind mill Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

About Horizontal wind mill

Discover the phenomenal Horizontal Wind Mill-engineered with first-rate materials like reinforced fiberglass blades and a robust aluminum alloy frame. Rated at 3 KW, this large, high-efficiency wind turbine boasts a generous rotor diameter of 2.6 meters and outputs a remarkable 5000 kWh annually. Operating quietly at less than 40 dB and equipped with an MPPT controller, electromagnetic and manual brakes, and triple protection systems, its safety and reliability garner favorable reviews across India. Shop now for exceptional markdown deals from leading dealers, wholesalers, and suppliers.

Distinctive Features & Versatile Applications

This aerodynamic horizontal axis wind turbine is lauded for its low-noise operation, weather resistance, and high wind energy conversion efficiency-achieving over 35% efficiency even under challenging circumstances. Designed for both residential and commercial users, it's also ideal for agriculture and rural electrification. Manufacturers, fabricators, and retailers across India consistently choose this robust structure for reliable renewable energy generation in a wide range of applications.

Reliable Supply Chain & Secure Logistics

Benefit from streamlined logistics with expedited drop-off and delivery services throughout India. Each wind mill is packaged in export-standard wooden boxes to guarantee safe transit. A sample policy is available, ensuring you experience our exceptional product quality firsthand before committing to bulk orders. Whether you're a producer, retailer, or end-user, rest assured your wind mill will be delivered on time and in perfect condition, ready for immediate ground-mounted installation.

FAQ's of Horizontal wind mill:

Q: How does the horizontal wind mill ensure safety during extreme weather conditions?

A: The wind mill incorporates over-speed, over-voltage, and lightning protection mechanisms, paired with an electromagnetic and manual brake system, to maintain safety even in high wind scenarios up to 50 m/s.

Q: What types of applications are suitable for this wind mill?

A: This wind mill is ideal for residential, commercial, and agricultural power generation, providing reliable and efficient electricity for a variety of needs in rural and urban environments.

Q: When can I expect my wind mill to be delivered after placing an order?

A: Delivery times depend on your location within India, but our logistics team ensures prompt drop-off, typically within a few working days after order confirmation.

Q: Where can the wind mill be installed?

A: Designed for ground-mounted installation, this wind turbine is suitable for open areas with consistent wind flow, such as rural land, commercial estates, and farm properties.

Q: What benefits does the MPPT charge controller offer?

A: The advanced MPPT (Maximum Power Point Tracking) charge controller optimizes energy conversion, allowing the wind mill to deliver exceptional efficiency and stable power output even in fluctuating wind conditions.

Q: How much maintenance does the wind mill require?

A: The wind mill is engineered for low-maintenance operation, thanks to its high-quality reinforced fiberglass blades, durable materials, and weather-resistant construction.
